D-436-38 by te connectivity / raychem brand
图片仅供参考 - 请查看制造商规格
TE Connectivity / Raychem Brand 授权经销商

D-436-38

The Sealed In-Line Crimp Splice from TE has been designed to provide immersion resistant in-line splices of 1 to 1 wires ranging from 16-12 AWG with insulations rated for 135°C. The splice consists of an Insulation Sleeve made with heat-shrinkable, radiation cross-linked modified polyvinylidene fluoride and Sealing Rings made of immersion resistant thermoplastic. Once situated, heat application allows the insulation sleeve to shrink providing a tight and secure fit. ...

查看数据表 询问数据表
符合 RoHS
BAG 包装
附件
请求编程报价
合规证书

描述

The D-436-38 Sealed In-Line Crimp Splice from TE Connectivity's Raychem Brand offers a reliable and secure solution for creating in-line splices of 1 to 1 wires. With a wire range of 16-12 AWG and insulation rated for 135°C, this splice is suitable for a wide range of applications. The splice features an Insulation Sleeve made of heat-shrinkable, radiation cross-linked modified polyvinylidene fluoride, ensuring excellent thermal and chemical resistance. Additionally, the Sealing Rings are made of immersion-resistant thermoplastic, providing extra protection against moisture and environmental factors. The splice is easily installed using heat application, allowing the insulation sleeve to shrink and form a tight and secure fit.

搜索关键词: D43638

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
TE Connectivity / Raychem Brand
部件编号:
D-436-38
别名/又称:
650076-000
计量单位:
每 Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
100
封装类型:
BAG

常见问题

D-436-38 是否符合 RoHS 标准？

是的，D-436-38 符合 RoHS 标准。

D-436-38 的交货期是多少？

D-436-38 的标准交货期约为 50 周。有库存的数量由 Master Electronics 发货。

有存货: 10,085

可立即发货

已订购: 5,000   可以发货 1/11/27
已订购: 5,000   可以发货 8/23/27

最小订购数量: 10

工厂交货期 50 周

价格 (USD)

数量
单价
10
$4.66
50
$3.79
100
$3.46
300
$3.32
500
$3.16
1,000
$3.01
2,500
$2.82
5,000 +
$2.81
