382A023-3-0 by te connectivity / raychem brand
Image is representational - see mfr. specs

382A023-3-0

TE Connectivity / Raychem Brand

The 382A023-3-0 is a semi-rigid, polyolefin, Y-shaped molded transition for cable harnessing applications. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 382A023-3-0 is a Y-shaped transition molded part used to create durable cable breakouts and junctions. Constructed from semi-rigid polyolefin, this heat-shrinkable component is supplied with a main entry diameter of 1.06 inches and two leg entry diameters of 0.52 inches. After heat application and unrestricted recovery, the main entry shrinks to a minimum diameter of 0.49 inches and the legs to 0.24 inches, providing a secure fit. This transition is commonly used in electrical harnessing to provide mechanical protection, strain relief, and environmental sealing for cable breakouts.

Product Highlights:

  • Molded Part Type = Transition
  • Family Name = 382A0
  • Transition Type = Y
  • 2 Branches/Legs
  • General Purpose Application

Search Keywords: 382A02330

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / Raychem Brand
部件编号:
382A023-3-0
Alias/AKA:
823765-000
计量单位:
Per Each
RoHS:
Yes
HTS:
3926909989
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Transition
Body Material:
Semi-Rigid Modified Polyolefin
Shrink Wall Type:
N/A
Styles:
Y Style
Shrink Ratio:
N/A
Dielectric Strength:
N/A
Color:
N/A
Operating Temperature:
-55 to 135 °C
Inside Diameter After Shrinking:
12.4/6.1/6.1 mm
Inside Diameter Before Shrinking:
26.9/13.2/13.2 mm

有存货: 110

可立即发货

Minimum Order Quantity: 5

工厂交货期 15 周

数量
Unit Price
5
$36.99
10
$35.54
25
$32.99
50
$31.42
100
$29.92
250 +
$28.05
Log in for special pricing Click for Quote Price Match Request
