DTM04-3P-E004
Conn Housing RCP 3 POS Crimp ST Cable Mount Black Box Automotive ...
描述
The DTM04-3P-E004 is a 3-position sealed receptacle connector from the DT Family series designed for industrial and commercial transportation applications. This connector is specifically engineered for J1939 3-wire CAN (Controller Area Network) systems, accommodating CAN_HI, CAN_LO, and shield wires for serial data communications between Electronic Control Units (ECUs). The receptacle features a welded flange with shrink boot adapter in black finish, providing enhanced environmental protection and improved aesthetics. It utilizes size 16 gold-plated contacts (pins or sockets) and is compatible with standard wire sealing ranges of 0.088–0.145 inches (2.23–3.68 mm) for 14–20 AWG wire. The connector is rated to operate in harsh environments from -70°F to +225°F (-56°C to +107°C) and supports network termination with optional molded-in 120O resistors. Common applications include vehicle electrical systems, agricultural equipment, construction machinery, and other heavy-duty transportation platforms requiring reliable CAN bus connectivity.
搜索关键词: DTM043PE004
规格
常见问题
DTM04-3P-E004 是否符合 RoHS 标准？
是的，DTM04-3P-E004 符合 RoHS 标准。
DTM04-3P-E004 的交货期是多少？
DTM04-3P-E004 的标准交货期约为 13 周。有库存的数量由 Master Electronics 发货。
有存货: 628
发货 today, 输入设置值。
最小订购数量: 25
工厂交货期 13 周
3D PDF
Product Drawing - DTM RECP ASM
数据表
Product Specification - DTM Series Connector System
