10CBS1 by te connectivity / corcom brand
图片仅供参考 - 请查看制造商规格
TE Connectivity / Corcom Brand 授权经销商

10CBS1

Power Entry Module EMI/RFI Filtered M 3 POS 250VAC 10A/Contact Switch ST 1 Port ...

查看数据表 询问数据表
符合 RoHS
Pack 包装
附件
请求编程报价
合规证书

描述

The 10CBS1 is a non-filtered power entry module combining a DPST switch and an IEC 60320-1 inlet with pre-connected line and switch terminals for snap-in mounting. It is rated for 10A at 250VAC with 50/60 Hz operating frequency and features a hipot rating of 2250 VDC line to ground and 1450 VDC line to line. The module includes six 0.187-inch spade terminals with 0.055-inch diameter holes and a ground terminal with a 0.112 x 0.06-inch slot, providing enhanced EMI attenuation through its two-element circuit design. This configuration reduces OEM wiring time and is ideal for applications requiring compact power distribution with integrated switching functionality in industrial and commercial equipment.

产品亮点:

  • Filter - EMI/RFI
  • Filter Type = Power Entry (Filtered/Unfiltered)
  • C (1-10 Amp) Series
  • General Purpose Application
  • Mount Style = Snap-in

搜索关键词: 10CBS1

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
TE Connectivity / Corcom Brand
部件编号:
10CBS1
别名/又称:
1609112-2
计量单位:
每 Each
RoHS:
Yes
HTS:
8537109170
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
210
封装类型:
Pack
类型:
EMI/RFI Filtered
本体方向:
Straight
公母类型:
M
安装方式:
Snap-In
端接方式:
Quick Connect
最大电压额定值:
250 VAC
最大电流额定值:
10/Contact A
工作频率:
50 to 30000 KHz
工作温度:
-10 to 40 °C

常见问题

10CBS1 是否符合 RoHS 标准？

是的，10CBS1 符合 RoHS 标准。

10CBS1 的交货期是多少？

10CBS1 的标准交货期约为 22 周。有库存的数量由 Master Electronics 发货。

有存货: 439

可立即发货

最小订购数量: 5

工厂交货期 22 周

价格 (USD)

数量
单价
5
$10.57
25
$10.44
50
$10.34
210
$9.90
420
$9.43
630
$9.16
1,050 +
$8.82
