609-1630LF by te connectivity / buchanan brand
Image is representational - see mfr. specs

609-1630LF

TE Connectivity / Buchanan Brand

Conn IDC Connector F 16 POS 2.54mm IDT RA Cable Mount ...

产品说明书
符合 RoHS 规定
Tray 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

609-1630LF is a 16-position female socket connector designed for ribbon cable interconnection applications. It features 0.100 inch [2.54 mm] center spacing and is available in both standard and military/center polarized configurations. The connector has a dimension A of 0.976 inches [24.79 mm], dimension B of 0.700 inches [17.78 mm], and dimension C of 0.892 inches [22.66 mm]. This connector is RoHS compliant and can be ordered with or without strain relief options. It is commonly used in data acquisition systems, instrumentation, and general-purpose ribbon cable interconnection where reliable, compact connections are required.

Product Highlights:

  • Connector Type = AMP-LATCH
  • Number of Positions = 16
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 6091630LF

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / Buchanan Brand
部件编号:
609-1630LF
Alias/AKA:
2-1658526-9
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
63
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-55 to 125 °C

有存货: 779

可立即发货

Minimum Order Quantity: 5

工厂交货期 13 周

PRICE (USD)

数量
Unit Price
5
$5.02
25
$4.57
63
$4.49
126
$4.39
252
$4.30
504
$4.21
1,008
$4.16
2,520 +
$4.11
Suppliers Standard Package
