4PCR-08-006
Conn Barrier Strip 8 POS 8.26mm Solder RA Thru-Hole 20A/Contact Package ...
描述
4PCR-08-006 is a right-angle printed circuit board mount barrier strip terminal block from the BUCHANAN Series #4 Tri-Barrier line. It features a 0.325" [8.26mm] pitch with #4-40 screw size spacing and wire clamp screw termination style. The terminal block is constructed with a thermoplastic polyamide housing rated UL94V-0 for flammability, with bright acid tin over copper alloy terminals. It supports a wire range of 12-22 AWG with electrical ratings of UL Class C 20 Amps at 150V and UL Class D 10 Amps at 300V, and operates up to 105°C maximum temperature. This RoHS compliant terminal block is ideal for PCB applications requiring secure wire connections in industrial and electronic equipment.
产品亮点:
- Barrier Strip
- Barrier Style = Single Row, Tri-Barrier
- Block Style = Open Bottom with Standoffs
- 8.26 mm Centerline
- Right Angle Mount Angle
搜索关键词: 4PCR08006
规格
常见问题
4PCR-08-006 是否符合 RoHS 标准？
是的，4PCR-08-006 符合 RoHS 标准。
4PCR-08-006 的交货期是多少？
4PCR-08-006 的标准交货期约为 27 周。有库存的数量由 Master Electronics 发货。
