770985-3 by te connectivity / amp brand
Image is representational - see mfr. specs

770985-3

TE Connectivity / AMP Brand

MINI UMNL PIN 26-22AWG AU LP ...

产品说明书
不符合 RoHS 规定
Bag 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

770985-3 is a loose piece pin contact designed for use in AMP Soft Shell Pin and Socket Connectors. This brass contact features a pre-tin finish and is designed for 26-22 AWG wire sizes with an insulation diameter range of 0.047-0.069 inches (1.19-1.75 mm). The connector system offers a voltage rating of 250 V AC or DC, dielectric withstanding voltage of 1.0 kVAC, and insulation resistance of 1000 megohms minimum. It is RoHS compliant and recognized under UL File No. E28476 and CSA File No. LR 7189. These contacts are commonly used in commercial and industrial applications requiring reliable electrical connections with easy assembly.

Product Highlights:

  • Contact
  • Mini-Universal MATE-N-LOK
  • Pin
  • Loose Piece
  • Wire Range = 0.12-0.40² [26-22] mm [AWG]

Search Keywords: 7709853

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
770985-3
计量单位:
Per Each
RoHS:
No
HTS:
8536904000
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Contact Type:
Power
Gender:
Pin
Contact Size:
N/A
Wire Size:
22-26 AWG
Contact Material:
Brass
Contact Plating:
N/A
Maximum Current Rating:
11.2 A
Termination Method:
Crimp
  This product is NOT RoHS Compliant.  See Alternatives

有存货: 0

已订购: 5,097   可以发货 6/29/26

Minimum Order Quantity: 50

工厂交货期 18 周

PRICE (USD)

数量
Unit Price
50
$0.701
250
$0.598
1,000
$0.518
3,000
$0.507
5,000
$0.506
8,000
$0.505
10,000
$0.504
15,000 +
$0.502
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南

附件

91529-1

Crimp Tool - Straight Action Hand Tool - 26AWG-22AWG - Hand - MATE-N-LOK Series - CERTICRI ...

90758-1

PROCRIMP TL W/DIE MIN UNIV MNL

90758-2

PROCRIMP DIE MINI UNIV MNL

189727-1

Extraction Tool for Mini-Universal MATE-N-LOK

455830-1

Insertion Tool for Universal MATE-N-LOK; Commercial MATE-N-LOK; Mini-Universal MATE-N-LOK
