The 747150-8 is an AMPLIMITE HD-20 subminiature D-type receptacle connector designed for secure PCB mounting with 4-40 threaded inserts. This straight posted connector features 9 contact positions in shell size 1 with dimensions of 1.216 inches (30.89 mm) length and 0.984 inches (24.99 mm) width, accommodating standard PCB board thickness of 0.083–0.125 inches (2.06–3.18 mm). The connector is constructed with a steel shell (tin plated), 94V-0 rated thermoplastic black housing, and brass threaded inserts, with socket contacts made from phosphor bronze featuring gold plating on the mating end and tin-lead on the termination end, along with nickel underplating. The preloaded size 20 DF posted socket contacts and threaded insert design provide reliable mating and secure retention for industrial and electronic equipment applications requiring robust interconnection solutions.
产品亮点:
- 9 Positions
- Receptacle
- PCB Mount Angle = Vertical
- Product Series = HD 20
- With Mating Connector Lock
搜索关键词: 7471508
规格
FREQUENTLY ASKED QUESTIONS
Is 747150-8 RoHS compliant?
No, 747150-8 is not RoHS compliant.
What is the lead time for 747150-8?
The standard lead time for 747150-8 is approximately 11 days. In-stock quantities ship from Master Electronics.
有存货: 1,011
发货 today, 输入设置值。
最小订购数量: 17
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。: 17
工厂交货期 11 周
价格 (USD)
3D PDF
产品指南
Product Drawing - RECEPTACLE ASSEMBLY, SIZE 1, 9 POSITION FRONT METAL SHELL, WITH OR WITHOUT SCREWLOCKS OR INSERTS,
数据表
Product Specification - AMPLIMITE HD-20 PCB Mounted Connector
