5748526-1

TE Connectivity / AMP Brand

KIT,PLUG,9P,HDP-20,SHLD HDWRE ...

产品说明书
符合 RoHS 规定
Bag 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

5748526-1 is an HDP-20 basic shielding hardware kit designed for 9-position D-subminiature plug connectors. This kit features shell size 1 with dimensions of 0.700 inches (Dim. D) and 1.535 inches (Dim. E), and supports a recommended cable outer diameter range of 0.165 to 0.455 inches with a maximum inner cable bundle diameter of 0.350 inches. The connector shell is made of steel with tin plating, and the insert is constructed from 94V-0 rated thermoplastic in black. It utilizes standard clinch nut mounting and accepts size 20 DF pin contacts. This shielding hardware kit is ideal for industrial machinery, medical instrumentation, computers and peripherals, and other applications requiring reliable D-subminiature connections with EMI shielding.

Product Highlights:

  • Connector Kit
  • Product Series = HDP-20 (Crimp Snap)
  • Number of Positions = 9
  • Shielded
  • Plug

Search Keywords: 57485261
