5747841-4 by te connectivity / amp brand
图片仅供参考 - 请查看制造商规格
TE Connectivity / AMP Brand 授权经销商

5747841-4

D Sub Connector - DB15 - Size 2 - 15 Contacts - Plug - Right Angle - Front Metal Shell - Boardlocks - AMPLIMITE HD-20 Series. ...

查看数据表 询问数据表
符合 RoHS
TRAY 包装
附件
请求编程报价
合规证书

描述

The 5747841-4 is a 15-way 2-row front metal shell D-sub Plug with gold-plated brass contacts and clear chromate-plated zinc 4-40 UNC threaded inserts. The Amplimite HD-20 series right angle posted plug comes with grounding indents, grounding straps, black nylon/polyester housing, tin-plated brass eyelet, tin-plated carbon steel shell and tin-plated solder tail. Plugs are preloaded with size 20 DF posted pin contacts. Connectors are intermateable with any size 20 subminiature D connectors dimensionally complying with MIL-C-24308. The front metal-shell design is compatible with full metal-shell connectors.

产品亮点:

  • Number of Positions = 15
  • Plug
  • PCB Mount Angle = Right Angle
  • Product Series = HD 20
  • With Mating Connector Lock

搜索关键词: 57478414

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
5747841-4
计量单位:
每 Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
供应商标准包装: 此信息提供给偏好按制造商标准包装数量的倍数购买的客户。最小订购数量和要求的订购倍数会与我们的价格和库存信息一起显示。
104
封装类型:
TRAY
类型:
D-Subminiature
本体方向:
Right Angle
安装方式:
Through Hole
公母类型:
Pin
端接方式:
Solder
外壳尺寸:
2
触点数量:
15
接触点镀层:
Gold over Nickel
工作温度:
-55 to 105 °C

FREQUENTLY ASKED QUESTIONS

Is 5747841-4 RoHS compliant?

Yes, 5747841-4 is RoHS compliant.

What is the lead time for 5747841-4?

The standard lead time for 5747841-4 is approximately 40 days. In-stock quantities ship from Master Electronics.

有存货: 5,724

可立即发货

最小订购数量: 5

工厂交货期 40 周

价格 (USD)

数量
单价
5
$4.47
50
$3.30
104
$3.25
312
$3.09
520
$2.98
1,040
$2.71
2,600
$2.66
5,096 +
$2.65
