5536501-3

TE Connectivity / AMP Brand

Header - Male Pins - Futurebus Style - 96 Position - 4 Rows - 0.079" (2.00mm) Pitch - 30V - Solder Termination - Through Hole. ...

产品说明书
符合 RoHS 规定
Tube 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 5536501-3 is header with board guide. Operating temperature range is from -55°C to 125°C.

Product Highlights:

  • Module Type = Signal
  • 96 Signal Positions
  • Fixed-Board (Header)
  • Mating Post Length = 6.50 mm
  • PCB Mount Angle = Vertical

Search Keywords: 55365013

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
5536501-3
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
12
Package Type:
Tube
Type:
Backplane
Gender:
HDR
Body Orientation:
Straight
Mounting:
Through Hole
Pitch:
2 mm
Number of Contacts:
96
Termination Method:
Solder
Operating Temperature:
-55 to 125 °C

有存货: 785

可立即发货

工厂库存: 720   可以发货 5/18/26

Minimum Order Quantity: 12

Multiple: 12

工厂交货期 2 周 可以发货 5/15/26

数量
Unit Price
12
$14.19
36
$13.98
60
$13.78
108
$13.41
252
$13.24
504
$11.14
1,008 +
$9.48
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

附件

5536507-3

2MM FB,ASY,096,SIG,REC,SL,2.73

5536510-3

RECEPTACLE ASSEMBLY, SIGNAL MODULE, Z-PACK 2mm FB,4 ROW, 3.53mm LEAD LENGTH

5536511-3

2MM FB,ASY,096,SIG,REC,EN,3.55

Show 1 More
