描述
4-794680-4 is a dual-row header connector designed for wire-to-board connections within TE Connectivity's Micro MATE-N-LOK 3mm connector system. This 14-position header features a 3mm (0.118 inch) centerline spacing and supports current ratings up to 5 Amps per line at 250 Volts AC/DC. The connector is available with 30 microinch gold plating, vertical angle orientation, and through-hole mounting configuration with metal hold-down options. It accommodates wire sizes from 22-18 AWG (0.3-0.9 mm²) with insulation diameters up to 2.79 mm, making it suitable for applications requiring reliable wire-to-board interconnections in compact spaces. This header is commonly used in appliance control systems, industrial equipment, and consumer electronics where space-efficient, high-reliability connections are essential.
产品亮点:
- Header Assembly
- Number of Positions = 14
- Number of Rows = Dual
- Vertical Mount Angle
- Mount Style = Through-Hole
搜索关键词: 47946804
规格
FREQUENTLY ASKED QUESTIONS
Is 4-794680-4 RoHS compliant?
Yes, 4-794680-4 is RoHS compliant.
What is the lead time for 4-794680-4?
The standard lead time for 4-794680-4 is approximately 19 days. In-stock quantities ship from Master Electronics.
有存货: 0
已订购:
1,573
可以发货 9/7/26
库存数量的起订量: 25
缺货数量的起订量: 394
工厂交货期 19 周
价格 (USD)
3D PDF
Product Drawing - VERTICAL HEADER ASSEMBLY, THRU HOLE, TIN, DUAL ROW, MICRO MATE-N-LOK(TM)
数据表
Product Specification - 3 mm Micro MATE-N-LOK Connector
