350789-3 by te connectivity / amp brand
Image is representational - see mfr. specs

350789-3

TE Connectivity / AMP Brand

03P UMNL PIN HDR ASSY 94VO ...

产品说明书
符合 RoHS 规定
Bag 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

350789-3 is a 3-circuit pin header connector from the 5.0 mm Power Key Connector (5.0 PKC) series, designed for wire-to-board power circuit applications. This in-line style connector features duplex plating with a minimum of 0.000030 inch (0.000762 mm) gold in the mating area and matte tin on the solder tail end over a minimum 0.000050 inch (0.00127 mm) nickel underplate. The header has a standard tail configuration suitable for 0.062 inch (1.57 mm) thick PC boards, with a dimension A of 0.800 inch (20.32 mm). It is rated UL94V-0 for flammability and features a compact design with 19.4 mm mated height and 5.0 mm contact centerline. Common applications include power circuits in home appliances, particularly gas appliances, where reliable power connections are required.

Product Highlights:

  • Header
  • Universal MATE-N-LOK, Universal MATE-N-LOK II
  • Not CompactPCI
  • 6.35 mm Centerline, Matrix
  • Number of Circuits = 3

Search Keywords: 3507893

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
350789-3
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Type:
Power
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
HDR
Number of Contacts:
3
Termination Method:
Solder
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
19/Contact A
Operating Temperature:
-65 to 105 °C

有存货: 14,943

可立即发货

Minimum Order Quantity: 100

Multiple: 100

工厂交货期 12 周

PRICE (USD)

数量
Unit Price
1
$2.299
100
$2.090
300
$1.960
500
$1.900
1,000
$1.820
2,500
$1.720
5,000 +
$1.640
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南

附件

350766-1

This housing from TE comes from their Wire to Board Universal MATE-N-LOK Connectors series ...

770018-1

3 Position Rectangular Housing Connector Plug White 0.250" (6.35mm)

350848-3

03P UMNL PLUG TEST ASSY 94VO

Show 1 More
