描述
2834048-2 is a 2-position LIGHT-N-LOK modular latched plug connector designed for wire-to-wire connections in indoor lighting applications. This compact connector features poke-in termination technology that enables tool-free field installation, with a black housing made from PA material rated UL94 V-0 and copper alloy contacts with tin plating. It supports current ratings up to 8A at 600V (UL1977) with 16-18 AWG wire and operates over a temperature range of -40°C to +105°C. The connector offers a voltage rating of 600 VAC maximum, dielectric strength of 2200 VAC, and durability up to 10 mating cycles. Its modular design and color-coded options make it ideal for space-constrained indoor lighting installations requiring reliable, easy-to-assemble connections.
搜索关键词: 28340482
规格
常见问题
2834048-2 是否符合 RoHS 标准？
是的，2834048-2 符合 RoHS 标准。
2834048-2 的交货期是多少？
2834048-2 的标准交货期约为 17 周。有库存的数量由 Master Electronics 发货。
有存货: 30,795
可立即发货
库存数量的起订量: 500
缺货数量的起订量: 500
工厂交货期 17 周
价格 (USD)
3D PDF
产品指南
数据表
Agency Approval Document - LIGHT-N-LOK Certificate of Conformity to IEC 61984
