222117-1 by te connectivity / amp brand
Image is representational - see mfr. specs

222117-1

TE Connectivity / AMP Brand

ADAPTER,JACK,BHD,75 OHM,BNC ...

产品说明书
符合 RoHS 规定
Carton 包装
附件
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

222117-1 is a 75 Ohm BNC bulkhead jack-jack adapter designed for RF coaxial connectivity applications. This adapter features a nickel-plated body, gold-plated center contact, and polymethylpentene dielectric material for reliable signal transmission. The connector has a diameter of 12.83 +0.13/-0.00 mm (0.505 +0.005/-0.00 in) and an inner diameter of 5.54 +0.08/-0.00 mm (0.218 -0.003/-0.00 in), with a maximum panel thickness of 6.35 mm (0.250 in). It utilizes 11/16-36.07 threading for secure panel mounting. This bulkhead adapter is ideal for panel-mount applications requiring reliable 75 Ohm impedance matching in RF communication systems.

Product Highlights:

  • Adapter
  • Connector Type = BNC
  • Jack
  • Not Stacked
  • 1 Ports

Search Keywords: 2221171

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
222117-1
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Carton
Type:
BNC Adapter
Impedance:
75 Ohm
Operating Frequency:
N/A
Gender:
RCP/RCP
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
N/A
Termination Method:
N/A
Operating Temperature:
N/A
Dimension:
36.07 x 20.27 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

有存货: 1,072

可立即发货

Minimum Order Quantity: 10

PRICE (USD)

数量
Unit Price
10
$8.68
40
$8.52
75
$8.35
150
$8.20
400
$8.04
500
$6.33
1,000 +
$5.43
