205559-2 by te connectivity / amp brand
Image is representational - see mfr. specs

205559-2

TE Connectivity / AMP Brand

RECEPT ASSY,25 POSN,AMPLIMITE ...

产品说明书
不符合 RoHS 规定
Pack 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

205559-2 is a Series 109 subminiature rectangular receptacle connector designed for military and industrial applications conforming to MIL-DTL-24308. It accommodates 25 contact positions in Shell Size 3 with standard mounting configuration. The connector features an outside dimension A of 1.511 inches (38.38 mm), outside dimension B of 0.311 inches (7.9 mm), and overall length C of 1.852 inches (47.04 mm). It is manufactured using the same high-reliability process as military-qualified connectors and supports AS39029 contacts for automatic machine termination. This receptacle-only configuration is ideal for permanent installation in high-use applications where connector savers are employed to preserve the mated connector, making it suitable for aerospace, military, and industrial equipment requiring robust, repeatable connections.

Product Highlights:

  • Connector
  • Product Series = 109
  • Density = Standard
  • Terminate To Wire
  • Number of Positions = 25

Search Keywords: 2055592

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
205559-2
Alias/AKA:
M24308/2-3F
计量单位:
Per Each
RoHS:
No
HTS:
8536694040
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Cable Mount
Gender:
SKT
Termination Method:
Crimp
Shell Size:
3
Number of Contacts:
25
Shell Plating Material:
Cadmium/Steel
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 125 °C

有存货: 0

工厂交货期 35 周

PRICE (USD)

数量
Unit Price
1
$46.62
25
$44.29
60
$42.08
100
$34.96
250
$26.54
500
$24.59
1,000 +
$23.95
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南

Product Changes
