描述
171630-1 is a socket contact for the Econoseal J Series sealed connector system, engineered for reliable wire-to-board connections in automotive environments. The contact is manufactured from brass with pre-tin plating and accommodates wire sizes from 0.2 to 0.5 mm² (AWG 24–20), with an insulation diameter range of 1.4–2.4 mm. It is designed to work with single wire seals (part number 178210-1, style B) and cavity plugs, providing waterproof protection against moisture, dust, corrosive gases, and liquids in extreme automotive conditions. This contact is commonly used in sensor wiring within motor hoods and electrical control systems operating under unfavorable climatic conditions, where sealed housing protection is essential to prevent premature contact degradation.
产品亮点:
- Contact
- Wire Range = 0.20-0.60² [24-20] mm [AWG]
- Contact Type = Receptacle
- Wire Insulation Diameter = 1.40 - 2.41 mm
- Brass Contact Material
搜索关键词: 1716301
规格
FREQUENTLY ASKED QUESTIONS
What replaces 171630-1?
The recommended replacement for 171630-1 is 173707-1 from TE Connectivity / AMP Brand, available from Master Electronics.
Is 171630-1 RoHS compliant?
Yes, 171630-1 is RoHS compliant.
What is the lead time for 171630-1?
The standard lead time for 171630-1 is approximately 18 days. In-stock quantities ship from Master Electronics.
3D PDF
Product Drawing - ECONOSEAL J MK-II CONN RECEPTACLE CONTACT
数据表
Product Specification - AMP Econoseal -J Mark II= Sensor Connector
Instruction Sheet - ECONOSEAL J MARK II+ CONNECTOR
