描述
The 1-480673-0 is a 9-circuit matrix pin housing (cap) connector designed for 5.0 mm Power Key Connectors (5.0 PKC) wire-to-board applications. This connector features a compact mated height of 19.4 mm and is constructed from nylon material with a UL94V-0 flammability rating, providing reliable performance in demanding environments. The housing incorporates positive lock mechanisms with protective walls surrounding the locking levers to prevent tangling with wires, and includes design features to release bubbles created during potting processes. Key dimensions include a width of 0.910 inches (23.11 mm) and a height of 0.755 inches (19.17 mm), with a 0.240 inch (6.09 mm) centerline spacing. This connector is commonly used in power circuits for home appliances, particularly gas appliances, where secure and reliable electrical connections are essential.
产品亮点:
- Housing
- 6.10 x 6.10 mm Centerline, Matrix
- Number of Circuits = 9
- Matrix Contact Layout
- Housing Type = Receptacle (Cap)
搜索关键词: 14806730
规格
FREQUENTLY ASKED QUESTIONS
What replaces 1-480673-0?
The recommended replacement for 1-480673-0 is 880125 from TE Connectivity / AMP Brand, available from Master Electronics.
Is 1-480673-0 RoHS compliant?
Yes, 1-480673-0 is RoHS compliant.
What is the lead time for 1-480673-0?
The standard lead time for 1-480673-0 is approximately 12 days. In-stock quantities ship from Master Electronics.
有存货: 823
可立即发货
最小订购数量: 200
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。: 200
工厂交货期 12 周
3D PDF
Product Drawing - CAP, 9 CIRCUIT, .140 MATE-N-LOK(TM)
数据表
Agency Approval Document - 0.140 PIN AND SOCKET CONNECTOR REPORT
Instruction Sheet - Universal, Commercial, and .140 MATE-N-LOK Contact and Housing Selection Charts
