1438618-1

TE Connectivity / AMP Brand

40 WAY ARM PLUG, KEY H NSB ...

产品说明书
符合 RoHS 规定
Pack 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The TE Connectivity / AMP Brand part 1438618-1 is a high-quality 40-way ARM plug connector designed for reliable and efficient connectivity in complex electronic systems. Featuring a keying option labeled as "H NSB", this connector ensures precise alignment and secure mating, minimizing connection errors. Constructed with durable materials and engineered for optimal performance, this 40-way plug is ideal for applications requiring robust signal integrity and long-term reliability. Its compact design allows for easy integration into various industrial and technological environments, making it a versatile choice for professionals seeking dependable connectivity solutions. Whether for high-speed data transfer or intricate wiring configurations, this ARM plug connector exemplifies the commitment to excellence and innovation synonymous with the TE Connectivity / AMP Brand.

Product Highlights:

  • Plug Assembly
  • Contact Type = Tab
  • Number of Rows = 4
  • 40 Positions
  • Positions Loaded = None

Search Keywords: 14386181

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
1438618-1
计量单位:
Per Each
RoHS:
Yes
HTS:
8536698000
COO:
US
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
Pack
Packaging Method:
Package
Number of Rows:
4
Circuit Application:
Signal
Terminal Position Assurance:
Yes
Number of Positions:
40
Primary Locking Feature:
Integrated in Housing
Sealable:
Yes
Degree of Protection:
IP67
Primary Product Color:
Black
Packaging Quantity:
60
Serviceable:
Yes
Connector Position Assurance Capable:
No
Connector & Housing Type:
Housing for female terminals
Cable Exit Angle:
180°
Centerline (Pitch):
.1 in, 2.54 mm
Product Width:
1.471 in, 37.37 mm
Product Length:
1.908 in, 48.47 mm
Connector System:
Wire-to-Board , Wire-to-Device
Mating Tab Width:
.025 in, .64 mm
Row-to-Row Spacing:
.189 in, .256 in, 4.8 mm, 6.5 mm
Operating Temperature Range:
-40 – 125 °C, -40 – 257 °F
Operating Temperature (Max):
100 °C, 105 °C, 110 °C, 120 °C, 125 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C
Contact Size:
.64mm
Strain Relief:
Without
Connector Mounting Type:
Cable Mount (Free-Hanging)
Mating Alignment Type:
Keyed
Housing Material:
PA GF
Mating Alignment:
With
Connector Shape:
Rectangular
Contact Type:
Receptacle
Connector Height:
1.322 in, 33.57 mm

有存货: 3

可立即发货

Buy all 3 in-stock or the regular minimum order quantity of 5

Stock lot only: 3

库存数量的起订量: 5

缺货数量的起订量: 420

工厂交货期 11 周

数量
Unit Price
1
$9.988
5
$9.080
100
$7.410
250
$7.000
420
$6.630
840
$6.360
1,260
$6.200
1,680 +
$6.180
