描述
The 130526 is a PIDG slotted spade tongue terminal designed for secure wire termination in electrical applications. It features a rectangular spade tongue configuration with a stud diameter of 3.02 mm and tongue thickness of 0.78 mm, accommodating wire sizes from 16 to 14 AWG (1.04 to 2.62 mm²). The terminal is fully insulated with a nylon insulation sleeve in blue, includes a closed barrel for reliable wire retention, and is tin-plated with a 2.54 µm plating thickness for corrosion resistance. With a maximum operating voltage of 600 V and operating temperature range up to 150°C, this terminal is suitable for heavy-duty electrical connections in automotive, industrial, and power distribution applications where durability and reliable contact are essential.
搜索关键词: 130526
规格
FREQUENTLY ASKED QUESTIONS
Is 130526 RoHS compliant?
Yes, 130526 is RoHS compliant.
What is the lead time for 130526?
The standard lead time for 130526 is approximately 30 days. In-stock quantities ship from Master Electronics.
有存货: 4,741
发货 today, 输入设置值。
库存数量的起订量: 100
缺货数量的起订量: 2500
工厂交货期 30 周
价格 (USD)
3D PDF
Product Drawing - TERMINAL, RECTANGULAR TONGUE, P.I.D.G. WIRE SIZE: 16-14 AWG
数据表
Product Specification - Pre-Insulated Diamond Grip (PIDG) Terminals, Splices, and End Caps
