1-1658621-0 by te connectivity / amp brand
Image is representational - see mfr. specs

1-1658621-0

TE Connectivity / AMP Brand

50 Position Rectangular Receptacle Connector IDC Gold 26-28 AWG ...

产品说明书
符合 RoHS 规定
Tray 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 1-1658621-0 is a 50-position 2-row vertical wire-to-board Ribbon Cable Pin Header with gold-plated phosphor bronze contacts and black UL94V-0 rated thermoplastic housing. Novo receptacles offer a dual contact interface with all normal force created by metal-to-metal contact. This provides a higher degree of contact reliability. Contacts mate with 0.642mm or round posts with 6.22mm maximum and 4.45mm minimum lengths. The Novo tuning fork contact offers a military-approved design. Insulation displacement contacts for fast, economical mass terminations Contact design provides uniform latching of contacts and housing with connector cover Accepts wire size range 28 to 26AWG (0.08 to 0.15mm²), solid or stranded Snap-on strain relief and choice of pull loops available One-step termination with Novo tooling Applications Defence, Military & Aerospace

Product Highlights:

  • Connector Type = NOVO
  • Number of Positions = 50
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 116586210

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
1-1658621-0
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
36
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
F
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
50
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

有存货: 6,060

可立即发货

工厂库存: 13,500   可以发货 5/18/26

已订购: 2,700   可以发货 5/25/26

Minimum Order Quantity: 36

Multiple: 36

工厂交货期 2 周 可以发货 5/15/26

数量
Unit Price
36
$1.93
108
$1.87
252
$1.81
504
$1.79
1,008
$1.78
2,520
$1.77
5,004
$1.76
7,524 +
$1.75
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
