1051942-1

TE Connectivity / AMP Brand

The 1051942-1 is a bulkhead mount SMA coaxial cable jack with a solder attachment for RG 174, 188, and 316 cables. ...

产品说明书
符合 RoHS 规定
Carton 包装
附件
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 1051942-1 is a bulkhead cable jack SMA connector designed for solder attachment to flexible RG 174, 188, and 316 coaxial cables. This connector features a gold-finished stainless steel body, ensuring durability and corrosion resistance. It is engineered to provide a VSWR of 1.15 + .01(fGHz) and a minimum insulation resistance of 10,000 megohms. The connector has a dielectric withstanding voltage of 750 Volts RMS and is rated for 500 mating cycles. Meeting the performance requirements of MIL-C-39012, this connector is suitable for applications in wireless communications, telecommunications infrastructure, and test equipment requiring a reliable, panel-mounted RF connection.

Product Highlights:

  • Connector
  • Jack
  • Connector Type = SMA
  • Terminate To Coaxial Cable
  • Without Snap-Lock

Search Keywords: 10519421

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
TE Connectivity / AMP Brand
部件编号:
1051942-1
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Carton
Type:
SMA
Impedance:
50 Ohm
Operating Frequency:
0 to 12 Hz to GHz
Gender:
RCP
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
34.93 x 7.9 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

有存货: 137

可立即发货

Minimum Order Quantity: 3

数量
Unit Price
3
$29.68
15
$28.55
50
$27.45
150
$26.39
400 +
$25.39
