134MPCX-3 by struthers-dunn

134MPCX-3

Struthers-Dunn

The 134MPCX-3 is a single-pole, double-throw (SPDT) miniature mercury wetted reed relay with a 24VDC coil. ...

产品说明书
不符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 134MPCX-3 is a miniature, SPDT mercury reed relay from the 134 series. It operates with a nominal coil voltage of 24VDC, features a coil resistance of 1400 ohms, and consumes a nominal power of 410 mW. The relay's contacts are rated for a maximum load of 50VA, with a maximum switching capability of 1 Amp at 500VDC and a carry current of 2 Amps. The use of liquid mercury in a hermetically sealed glass tube provides continuously refreshed contact surfaces, resulting in an extremely long electrical life expectancy. This makes the relay ideal for applications requiring high-repetition and reliable switching performance.

Search Keywords: 134MPCX3

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Struthers-Dunn
部件编号:
134MPCX-3
计量单位:
Per Each
RoHS:
No
HTS:
8536410020
COO:
IN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1

有存货: 12

可立即发货

工厂交货期 16 周

数量
Unit Price
1
$150.64
5
$146.76
10
$114.67
20
$113.21
50
$76.45
100 +
$65.46
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
