描述

TE60A1203F01 is a 60W single-output AC-DC external power supply designed for test and measurement and industrial applications. It delivers 12.0V at 5.00A maximum output current with 120mV pk-pk ripple and noise, featuring ±1% line regulation and ±5% load regulation. The unit accepts universal AC input from 90-264Vac at 47-63Hz, includes an IP22-rated enclosure, and meets DoE Efficiency Level VI requirements with over 900,000 hours MTBF and an 8-year E-cap life. It is fully compliant with EN/IEC/UL60950-1 safety standards, EN61000 heavy industrial EMC requirements, and FCC Part 15 Class B emissions standards. The output cable is 1150mm long with UL2464 18AWG 4-conductor wire terminated in a 2.5 x 5.5 x 9.5mm straight barrel connector with center positive polarity, and the input uses a Class I Desktop IEC60320 C14 connector. This power supply is ideal for laboratory equipment, industrial control systems, and other applications requiring reliable, regulated DC power with excellent EMC performance.
