GSM11-12AAG by sl power / advanced energy
图片仅供参考 - 请查看制造商规格

GSM11-12AAG

AC/DC Power Supply Single-OUT 12V 0.92A 11W Medical ...

查看数据表 询问数据表
符合 RoHS
包装
附件
请求编程报价
合规证书

描述

GSM11-12AAG is an 11 Watt single output AC/DC power supply designed for medical device applications. It features a universal input voltage range of 85-264 Vac, delivers 12V output at 0.92A with 120 mV ripple and 2% regulation, and includes overvoltage and short circuit protection. The unit operates with a fixed switching frequency of 80 KHz and achieves 67-77% efficiency at 120 Vac. With safety approvals to UL/EN/IEC 60601-1 and UL/EN/IEC 60950-1 standards, Class II input, and RoHS compliance, this compact power supply is ideal for small single board computers, battery charging, and running small motors, pumps, and solenoids in medical environments.

搜索关键词: GSM1112AAG

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
SL Power / Advanced Energy
部件编号:
GSM11-12AAG
计量单位:
每 Each
RoHS:
Yes
HTS:
8504409510
COO:
MX
ECCN:
EAR99
供应商标准包装: 供应商原始包装中所含物品的数量、长度、重量或体积,以便高效存储、搬运和配送。
240
AC输入电压:
85 to 264 V
尺寸:
57.91 x 50.8 x 15.82 mm

常见问题

GSM11-12AAG 是否符合 RoHS 标准?

是的,GSM11-12AAG 符合 RoHS 标准。

GSM11-12AAG 的交货期是多少?

GSM11-12AAG 的标准交货期约为 18 周。有库存的数量由 Master Electronics 发货。

有存货: 107

发货 today, 输入设置值。

缺货数量的起订量: 60

工厂交货期 18 周

价格 (USD)

数量
单价
1
$78.02
10
$71.26
25
$69.56
60
$67.87
120
$65.93
180
$65.76
240 +
$65.60
