D2450-10 by sensata / crydom
Image is representational - see mfr. specs

D2450-10

Sensata / Crydom

Solid-State Relay - Control Voltage 3-32 VDC - Max Input Current 12 mA - Output 24-280 VAC - Max Load Current 50 A - 4 Pins - 1 Form A - Screw Termination ...

产品说明书
符合 RoHS 规定
EACH 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The D2450-10 is a solid-state relay series 1 with SCR output for heavy industrial loads. Input control voltage range is 3-32 VDC. Operating voltage is 24-280 VAC and the max load current is 50 A. Series 1 relay has redesigned housing with anti-rotation barriers. I/O isolation voltage is 4000 Vrms. Switching type: instantaneous turn-on. Mounting type: panel mount.

Search Keywords: D245010

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Sensata / Crydom
部件编号:
D2450-10
计量单位:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
50(RMS) A
Output Device:
SCR
Input Type:
DC
Input Voltage:
32 V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
58.4 x 45.7 x 23 mm

有存货: 416

可立即发货

已订购: 1,000   可以发货 8/6/26

工厂交货期 17 周

数量
Unit Price
1
$67.85
5
$54.71
20
$52.47
40
$52.20
60
$51.94
100
$51.41
260 +
$50.77
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Older Equivalent
CSW2450-10
CSW2450-10
VIEW PRODUCT
