A2490E-10 by sensata / crydom
Image is representational - see mfr. specs

A2490E-10

Sensata / Crydom

Relay SSR 3mA 36V AC/DC-IN 90A 280V AC-OUT 4-Pin ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The A2490E-10 is a panel-mount solid-state relay designed for industrial AC load switching with 90 A maximum load current and 18-36 VAC control input range. It features SCR output technology suitable for heavy industrial loads, with zero-crossing turn-on for resistive loads and random-fire capability for inductive loads. The relay operates over an output voltage range of 24-280 VAC (47-63 Hz) with a maximum on-state voltage drop of 1.6 V at rated current and transient overvoltage protection rated at 600 V peak. With a thermal resistance of 0.28 °C/W (junction to case) and maximum 1-cycle surge current of 1200 A peak at 60 Hz, this relay is well-suited for demanding industrial applications including motor control, heating element switching, and power distribution systems requiring reliable AC switching with UL/CSA/VDE approval and CE compliance.

Search Keywords: A2490E10

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Sensata / Crydom
部件编号:
A2490E-10
计量单位:
Per Each
RoHS:
Yes
HTS:
8541409500
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
90(RMS) A
Output Device:
SCR
Input Type:
AC,DC
Input Voltage:
36(RMS) V
Mounting:
Screw
Circuit Arrangement:
N/A
Dimension:
58.4 x 45.7 x 23 mm

有存货: 15

可立即发货

工厂交货期 10 周

PRICE (USD)

数量
Unit Price
1
$103.90
5
$101.82
10
$99.78
25
$97.78
50
$95.84
100 +
$93.92
