66L080 by sensata / airpax
Image is representational - see mfr. specs

66L080

Sensata / AIRPAX

Thermostat Switch - Subminiature - Bimetal Disc - 6700 Series - 80 °C - Normally Closed - TO-220. ...

产品说明书
符合 RoHS 规定
Tube 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The 6700 series from Airpax are positive snap action, single pole single throw, sub-miniature bimetallic thermostat. This device provides accurate, reliable sensing and switching. The 6700 provides fast, positive response with excellent repeatability. The thermostat has a switch capability of upto 0.5A for 48VDC and achieves low level switching down to 0.001A to 0.020A at 5VDC for 100,000 cycles. It is primarily developed for thermal management applications on power supplies, the Airpax 6700 series is also ideally suited for use on crowded PC boards. Typical application include turning on indicator light, sounding an audible alarm, switch on a control circuit to send a message to a display screen or even switching a circuit to shut down a system.

Search Keywords: 66L080

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Sensata / AIRPAX
部件编号:
66L080
计量单位:
Per Each
RoHS:
Yes
HTS:
903210009
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Tube
Close Temperature (Celsius):
55 °C
Close Temperature (Fahrenheit):
131 °F
Maximum Current Rating:
1 A
Maximum AC Voltage Rating:
120 V
Maximum DC Voltage Rating:
48 V
Mounting:
PCB Through Hole
Pole Throw Configuration:
SPST
Switch Configuration:
N.C.
Operating Temperature:
40°C to 130 °C
Set Point Function:
Open on Rise
Open Temperature (Celsius):
80 °C
Open Temperature (Fahrenheit):
176 °F

有存货: 1,322

可立即发货

Minimum Order Quantity: 5

工厂交货期 9 周

数量
Unit Price
5
$10.41
25
$7.18
50
$6.74
100
$6.17
300
$6.10
500
$6.03
1,000 +
$6.00
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
