SSQ-104-01-G-D
The SSQ-104-01-G-D is a double-row, 8-pin through-hole socket with a 2.54 mm pitch and square tails for board-to-board connections. ...
描述
The SSQ-104-01-G-D is a through-hole square tail post socket designed for reliable interconnects. It is configured in a double-row layout with 4 pins per row on a (2.54 mm) .100" pitch. This component features phosphor bronze contacts with 20 µ" (0.51 µm) gold plating and an insulator made of black liquid crystal polymer. It has a current rating of 6.3 A per pin, a voltage rating of 465 VAC / 655 VDC, and an operating temperature range of -55 °C to +125 °C. This socket is ideal for applications requiring durable, high-cycle connections and mates with various headers such as the TSW and TSM series.
搜索关键词: SSQ10401GD
规格
常见问题
SSQ-104-01-G-D 是否符合 RoHS 标准？
是的，SSQ-104-01-G-D 符合 RoHS 标准。
SSQ-104-01-G-D 的交货期是多少？
SSQ-104-01-G-D 的标准交货期约为 2 天。有库存的数量由 Master Electronics 发货。
有存货: 425
可立即发货
制造商库存: 355 可以发货 9/21/26
最小订购数量: 10
工厂交货期 2 周 可以发货 9/21/26
价格 (USD)
Test Reports
产品指南
数据表
