QSH-030-01-C-D-A-K-TR by samtec
图片仅供参考 - 请查看制造商规格
Samtec 授权经销商

QSH-030-01-C-D-A-K-TR

A 0.5mm pitch, double-row, high-speed socket assembly with 30 positions per row, featuring alignment pins and a polyimide film pad for automated assembly. ...

查看数据表
符合 RoHS
Reel 包装
附件
请求编程报价
合规证书

描述

The QSH-030-01-C-D-A-K-TR is a high-speed, 0.5mm pitch double-row socket assembly designed for board-to-board interconnects. This model provides 30 positions per row and has a lead style of .1280 inches (3.25mm). The contacts are made from phosphor bronze and feature 50µ" electro-polished selective gold plating in the contact area with a matte tin finish on the tails for reliable connectivity. This specific configuration includes alignment pins for precise mating, a polyimide film pad to facilitate automated pick-and-place processes, and is supplied in tape and reel packaging. Its robust construction with an LCP insulator makes it suitable for high-density applications requiring durable, high-speed connections.

搜索关键词: QSH03001CDAKTR

规格

产品属性
属性值
选择属性
找到的产品: 0
供应商:
Samtec
部件编号:
QSH-030-01-C-D-A-K-TR
计量单位:
每 Each
RoHS:
Yes
HTS:
8536694040
COO:
CR
ECCN:
EAR99
卷盘包装: 此信息适用于希望按制造商标准包装数量的倍数购买的客户。最低订购数量和要求的订购倍数会与价格和库存信息一同显示。
1
封装类型:
Reel

常见问题

QSH-030-01-C-D-A-K-TR 是否符合 RoHS 标准？

是的，QSH-030-01-C-D-A-K-TR 符合 RoHS 标准。

QSH-030-01-C-D-A-K-TR 的交货期是多少？

QSH-030-01-C-D-A-K-TR 的标准交货期约为 2 天。有库存的数量由 Master Electronics 发货。

有存货: 801

可立即发货

制造商库存: 159   可以发货 9/4/26

最小订购数量: 5

工厂交货期 2 周 可以发货 9/15/26

价格 (USD)

数量
单价
5
$7.55
25
$6.90
50
$6.63
100
$6.35
250
$5.61
500
$5.35
1,000
$4.76
2,500 +
$4.12
登录以获取特别价格 点击询价 价格匹配请求
