Q2-F3X-1/8-01-MS100FT by qualtek electronics
Image is representational - see mfr. specs

Q2-F3X-1/8-01-MS100FT

Qualtek Electronics

The Q2-F3X-1/8-01-MS100FT is a flexible, flame-retardant polyolefin heat shrink tubing with a 3:1 shrink ratio designed for electrical insulation and mechanical protection. ...

产品说明书
符合 RoHS 规定
Tray 包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The Q2-F3X-1/8-01-MS100FT is a highly flexible, flame-retardant polyolefin heat shrink tubing. This 1/8-inch tubing features a 3:1 shrink ratio, reducing from a minimum supplied inside diameter of 3.2 mm to a maximum recovered diameter of 1.0 mm with a final wall thickness of 0.55 mm. It is rated for an operating temperature range of -55°C to +135°C and begins to shrink at 70°C. Key electrical properties include a dielectric strength over 20 kV/mm and a 600V rating. Due to its high flexibility and shrink ratio, it is ideal for electrical insulation, bundling, marking, and providing mechanical and corrosion protection, especially over irregular shapes.

Search Keywords: Q2F3X1801MS100FT

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Qualtek Electronics
部件编号:
Q2-F3X-1/8-01-MS100FT
计量单位:
Per Spool
RoHS:
Yes
HTS:
3926909985
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5
Package Type:
Tray
Type:
Tubing
Body Material:
Polyolefin
Shrink Wall Type:
Thin
Styles:
Straight
Shrink Ratio:
3:1
Dielectric Strength:
20 KV/mm
Operating Temperature:
-55 to 135 °C

有存货: 90 Spools

可立即发货

Minimum Order Quantity: 5 Spools

Multiple: 5 Spools

工厂交货期 25 周

数量
Unit Price
5
$7.84
25
$6.50
50
$6.04
100
$6.00
250
$5.97
500
$5.94
1,000 +
$5.91
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
