RAD-2400-IFS
Radioline - 2.4 GHz wireless transceiver with RS-232/RS-485 interface - can be extended with I/O modules - RSMA (female) antenna connection - point-to-point - star - and mesh networks up to 250 stations - range of up to 5 km (with a clear line of sight) - for worldwide use ...
描述
Radioline is the new wireless system for large systems. Special features include extremely easy assignment of inputs and outputs by simply turning the thumbwheel - without any programming. Radioline transmits I/O signals (I/O mode) or serial data (serial mode) and is therefore very versatile. Alternatively, I/O signals can now also be connected to controllers directly using the Modbus protocol (PLC/Modbus RTU mode). In addition, you can implement various network structures: from a simple point-to-point connection to complex mesh networks. Thanks to the latest Trusted Wireless technology, Radioline is the ideal choice for industrial use. Series Radioline Series Connector Type COMBI Plug Depth 114.5 mm Frequency 2400 MHz Height 99 mm Interface RS232, RS485 2-Wire Contact Material PdRu, gold-plated Housing Material PA 6.6-FR Screw Type M3 Termination Screw Type Trasnceiver Width 17.5 mm Wire Termination Type Screw
搜索关键词: RAD2400IFS
规格
常见问题
RAD-2400-IFS 是否符合 RoHS 标准？
是的，RAD-2400-IFS 符合 RoHS 标准。
RAD-2400-IFS 的交货期是多少？
RAD-2400-IFS 的标准交货期约为 5 周。有库存的数量由 Master Electronics 发货。
有存货: 0
制造商库存: 15 可以发货 10/16/26
工厂交货期 5 周 可以发货 11/5/26
价格 (USD)
工具/3D模型
产品指南
数据表
