描述

Phoenix Contact UNO POWER DIN Rail Power Supplies provides a compact solution for loads up to 240W. The UNO POWER product range offers performance classes ranging from 25 to 240W at output voltages of 5 to 48VDC. Housing widths of 22.5mm, 35mm, and 55mm, make the series ideal for compact control boxes. Maximum energy efficiency is provided with more than 90% across the operating range of -25°C to +70°C, as well as idle losses below 0.3W. Select models are certified according to UL 1310/508 Listed Class 2. The Phoenix Contact UNO POWER DIN Rail Power Supplies offer more amperage, voltage, and power ratings to meet most applications. FEATURES High power density and tailored to all conventional 120mm control cabinets Basic functionality for 24VDC and 12VDC requirements making the power supplies a reliable choice for low-cost applications. Wide operating temperature range of -25°C to +70°C making it flexible for all applications. Wide input range of 85VAC to 264VAC for worldwide use More than 700,000-hour MTBF rating at full nominal load
