1829345 by phoenix contact
Image is representational - see mfr. specs

1829345

Phoenix Contact

Feed-through header - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 2 - pitch: 3.81 mm - connection method: Solder/Slip-on connection - color: green - contact surface: Tin - mounting: Direct mounting - pin layout: Linear pinning - solder pin [P]: 9.4 mm ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The PHOENIX CONTACT part 1829345 is a feed-through header designed for reliable electrical connections. It has a nominal current rating of 8 A and a rated voltage of 160 V. The header features a 1.5 mm² nominal cross section and comes with 2 positions and a 3.81 mm pitch. The connection method is solder/slip-on, ensuring secure and efficient connections. The header is color-coded green and has a tin contact surface. It can be directly mounted for easy installation. The pin layout is linear, with a solder pin spacing of 9.4 mm. Overall, this feed-through header offers robust performance and is a reliable choice for various electrical applications.

Search Keywords: 1829345

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Phoenix Contact
部件编号:
1829345
Alias/AKA:
DFK-MC-1-5/-2-GF-3-81
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
PL
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Panel Mount
Pitch:
3.81 mm
Number of Contacts:
2
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

有存货: 240

可立即发货

Minimum Order Quantity: 50

Multiple: 50

工厂交货期 5 周

数量
Unit Price
50
$3.46
100
$3.38
250
$3.31
500
$3.27
1,000
$3.22
2,500
$3.21
5,000 +
$3.20
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

附件

0710015

Screw set - for securing the header to the housing wall - consists of M2 x 8 screw - sprin ...

0804109

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...

1734634

Coding profile - is inserted into the slot on the plug or inverted header - red insulating ...

Show 2 More
