1729018 by phoenix contact
Image is representational - see mfr. specs

1729018

Phoenix Contact

PCB terminal block - nominal current: 13.5 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 5 mm - number of positions: 2 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The PHOENIX CONTACT part 1729018 is a PCB terminal block with a nominal current of 13.5 A. It has a rated voltage of 400 V and a nominal cross-section of 1.5 mm². The terminal block has a 5 mm pitch and consists of 2 positions. The connection method is a screw connection with a tension sleeve. It can be mounted using wave soldering. The conductor/PCB connection direction is 0 ° and the color of the terminal block is green. The pin layout is linear pinning with a solder pin length of 3.5 mm.

Search Keywords: 1729018

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Phoenix Contact
部件编号:
1729018
Alias/AKA:
MKDSN-1-5/-2
计量单位:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
260
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
5 mm
Number of Circuits:
2
Maximum Voltage Rating:
400 V
Maximum Current Rating:
13.5 A
Wire Size:
16-26 AWG
Operating Temperature:
-40 to 100 °C

有存货: 1,796

可立即发货

已订购: 4,160   可以发货 6/12/26
已订购: 3,900   可以发货 7/13/26

Minimum Order Quantity: 25

工厂交货期 11 周

数量
Unit Price
25
$1.006
260
$0.749
520
$0.734
1,040
$0.727
2,600
$0.723
5,200
$0.720
7,540
$0.716
10,140 +
$0.712
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

Product Changes

附件

0804183

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

0805409

Marker card - Card - white - unlabeled - can be labeled with: Marker pen - mounting type: ...

1051993

Marker pen - for manual labeling of unprinted Zack strips - smear-proof and waterproof - l ...

Show 1 More
