1727036 by phoenix contact
Image is representational - see mfr. specs

1727036

Phoenix Contact

PCB terminal block - nominal current: 13.5 A - rated voltage (III/2): 200 V - nominal cross section: 1.5 mm² - pitch: 3.81 mm - number of positions: 4 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The PHOENIX CONTACT part 1727036 is a PCB terminal block designed for reliable and efficient electrical connections. With a nominal current of 13.5 A and a rated voltage of 200 V, this terminal block is suitable for various applications. It has a nominal cross section of 1.5 mm², making it suitable for medium power systems. The terminal block features a screw connection with a tension sleeve for secure and durable connections. It has a pitch of 3.81 mm, allowing for efficient PCB layout and assembly. With four positions available, multiple connections can be made using a single terminal block.This terminal block is designed for easy mounting through wave soldering, ensuring effective and efficient installation. The conductor/PCB connection direction is 0°, providing flexibility in system design. The terminal block has a vibrant green color, making it easily identifiable in a densely populated circuit board. The pin layout of this terminal block is linear, providing a neat and organized arrangement of connections. The solder pin has a length of 3.5 mm, allowing for easy soldering and ensuring a secure connection.Overall, the PHOENIX CONTACT part 1727036 is a high-quality and versatile PCB terminal block that offers reliable electrical connections, efficient installation, and excellent performance in various applications.

Search Keywords: 1727036

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Phoenix Contact
部件编号:
1727036
Alias/AKA:
MKDS-1/-4-3-81
计量单位:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.81 mm
Number of Circuits:
4
Maximum Voltage Rating:
200 V
Maximum Current Rating:
13.5 A
Wire Size:
16-26 AWG
Operating Temperature:
N/A

有存货: 271

可立即发货

已订购: 500   可以发货 6/3/26

Minimum Order Quantity: 10

工厂交货期 4 周

数量
Unit Price
10
$2.59
100
$2.16
250
$2.03
500
$1.95
1,000
$1.90
2,500
$1.85
5,000
$1.82
7,500 +
$1.79
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

Product Changes

附件

0804109

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1051993

Marker pen - for manual labeling of unprinted Zack strips - smear-proof and waterproof - l ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...

Show 1 More
