DPH-103-R by panasonic / sunx
Image is representational - see mfr. specs

DPH-103-R

PANASONIC / SUNX

The DPH-103-R is a head-separated vacuum pressure sensor head for measuring gauge pressure in air and non-corrosive gases. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The DPH-103-R is a head-separated vacuum pressure sensor head designed to measure gauge pressure within a rated range of 0 to –101.0 kPa. It operates on a 12 to 24 V DC supply and is suitable for use with air and other non-corrosive gases, featuring a pressure withstandability of 500 kPa. This model is equipped with a flexible, oil-resistant cabtyre cable for durable and versatile installations. The sensor is constructed with a stainless steel (SUS303) pressure port and a silicon diaphragm pressure element. Designed for industrial environments, it functions reliably within an ambient temperature range of 0 to +50 °C.

Search Keywords: DPH103R

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
PANASONIC / SUNX
部件编号:
DPH-103-R
计量单位:
Per Each
RoHS:
Yes
HTS:
902620190
COO:
JP
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Media:
Air,Gas
Output Voltage:
1 to 5 V
Mounting:
Panel
Operating Temperature:
0 to 50 °C
Dimension:
28.2 x 13.2 x 23 mm
Device Pressure Type:
Vacuum Gage
Operating Pressure Range:
0 to 101 kPa
Accuracy:
±0.5 %
Typical Operating Supply Voltage:
12 to 24 V
Response Time:
Selectable
Electrical Termination:
Connector

有存货: 9

可立即发货

工厂交货期 12 周

数量
Unit Price
1
$68.58
5
$65.93
10
$64.98
20
$63.23
50
$62.42
100 +
$62.04
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

附件

CN-66A

6-core Connector 5 connectors per box

CN-72-C1

CN-66A-C2

6-core. 2M Cable for DPC Controller

CN-72-C2

QD CONNECTOR WITH 2 M SUB CABLE

CN-66A-C5

6-core. 5M Cable for DPC Controller

CN-72-C5

CN-74-C1

Cordset; QD Connector With 1m Main Cable

CN-74-C2

Cable Assembly Power 2m Power 4 POS F

CN-74-C5

Quick connection - main 4 core cable - 5m length - Panasonic / SunX (CN)

CN-EP1

Connector, Including 5 Pieces | Panasonic Industrial Automation CN-EP1

CN-EP2

Conn Hook Up Connector

MS-DIN-2

Amplifier - Mounting Bracket

MS-DP1-2

Mounting Bracket - Panel Mount - DP 100 Series Sensors

MS-DP1-3

Front Protection Cover For DP-100.
