TQ2-9V by panasonic electronic components
Image is representational - see mfr. specs

TQ2-9V

Panasonic Electronic Components

Signal Relay 9VDC 1A DPDT(14x9x5)mm THT ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The PANASONIC EW/AROMAT part TQ2-9V is a compact and reliable signal relay designed for various electronic applications. With a coil voltage of 9VDC and a contact rating of 1A, this DPDT (Double Pole Double Throw) relay is capable of efficiently switching or routing signals in electronic circuits. Its compact dimensions of 14x9x5mm make it suitable for space-constrained applications. The Through-Hole Technology (THT) allows for easy installation and secure soldering onto PCBs. Trust the PANASONIC EW/AROMAT TQ2-9V relay for its exceptional quality and performance for your signal switching needs.

Search Keywords: TQ29V

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Panasonic Electronic Components
部件编号:
TQ2-9V
计量单位:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
JP
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
9 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
1 A
Mounting:
Through Hole12526
Operating Temperature:
-40 to 70 °C
Dimension:
14 x 9 x 5 mm
Termination Style:
PC Pin12536
Coil Current:
15.5 mA
Contact Form:
2 Form C12515

有存货: 7,876

可立即发货

Minimum Order Quantity: 50

Multiple: 50

工厂交货期 16 周

数量
Unit Price
50
$1.84
100
$1.82
250
$1.77
500
$1.75
1,000
$1.43
2,500
$1.41
5,000
$1.39
7,500 +
$1.38
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
