JW1AEN-DC24V by panasonic electronic components
Image is representational - see mfr. specs

JW1AEN-DC24V

Panasonic Electronic Components

Power Relay 24VDC 10A SPST-NO (( 28.6mm 12.8mm 20mm)) Through Hole ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

JW1AEN-DC24V is a miniature power relay from the Panasonic JW relay series designed for general-purpose switching applications. It features a 1 Form A (SPST-NO) contact arrangement with a standard 5A contact capacity and operates with a 24V DC rated coil voltage. The relay has compact dimensions of 12.8 mm width × 28.6 mm length × 20 mm height, making it suitable for space-constrained PCB designs. It offers switching capabilities of 5A at 250V AC and 5A at 30V DC for resistive loads. Common applications include home appliances, office machines, and industrial equipment where reliable power switching is required.

Search Keywords: JW1AENDC24V

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Panasonic Electronic Components
部件编号:
JW1AEN-DC24V
计量单位:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
10 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
1.1 KOhm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

有存货: 148

可立即发货

Minimum Order Quantity: 4

PRICE (USD)

数量
Unit Price
4
$19.42
50
$6.75
100
$4.90
500
$4.44
1,000
$4.22
5,000
$3.91
10,000 +
$3.88
