G6K-2P-DC5 by omron electronics
Image is representational - see mfr. specs

G6K-2P-DC5

Omron Electronics

Signal Relay 5VDC 1A DPDT(10x6.5x5)mm THT ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The G6K-2P DC5 is a Subminiature Relay with DC coil. This G6K-series surface mount subminiature relay has 2CO (DPDT) Ag contact with PCB terminals. Consumes approximately 70% the power of a conventional OMRON model and operates at a current that is as low as 100mW. Surface mounting terminal models incorporate a unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering. Single side stable function Fully sealed enclosure Low profile of 5.2mm improves mounting efficiency -40 to 70°C Operating temperature range Applications Industrial, Communications & Networking, Test & Measurement, Security, Automation & Process Control, Consumer Electronics, Building Automation

Search Keywords: G6K2PDC5

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Omron Electronics
部件编号:
G6K-2P-DC5
计量单位:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
10 x 6.5 x 5 mm
Termination Style:
PC Pin
Coil Current:
21.1 mA
Contact Form:
2 Form C

有存货: 4,488

可立即发货

Minimum Order Quantity: 10

工厂交货期 4 周

数量
Unit Price
10
$3.93
50
$3.19
100
$3.18
250
$2.96
500
$2.80
1,000
$2.79
2,500
$2.65
5,000 +
$2.62
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南

Product Changes
