MOX-750232505FE by ohmite
Image is representational - see mfr. specs

MOX-750232505FE

Ohmite

The MOX-750232505FE is a precision, high-voltage, thick-film axial resistor with a resistance of 25 MOhms and a 1% tolerance. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The MOX-750232505FE is a standard epoxy-coated, high-voltage/high-resistance resistor from the Mini-Mox series, designed for precision circuits. It provides a resistance of 25 MOhms with a tolerance of 1%, a power rating of 1.00W at 25°C, and a maximum operating voltage of 5,000V. Constructed with a metal oxide resistive element, this component features a low capacitance of 0.75 pF and an operating temperature range of -55°C to +220°C. Its stable characteristics make it ideal for demanding applications such as medical electronics, avionics, high gain feedback circuits, and current pulse limiters.

Search Keywords: MOX750232505FE

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Ohmite
部件编号:
MOX-750232505FE
计量单位:
Per Each
RoHS:
Yes
COO:
MX
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Termination Style:
Axial
Power Rating:
1 W
Resistance Value:
25 mOhm
Tolerance:
1 %
Temperature Coefficient:
±25 ppm/°C
Operating Temperature:
-55 to 220 °C
Packaging:
N/A
Dimension:
22.35 x 4.19 mm
Terminal Pitch:
N/R

有存货: 450

可立即发货

Minimum Order Quantity: 5

工厂交货期 20 周

数量
Unit Price
5
$16.12
10
$15.77
25
$15.12
50
$14.39
100
$13.98
250 +
$13.67
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

产品指南
