EC2-5NJ by nexem
Image is representational - see mfr. specs

EC2-5NJ

Nexem

The EC2-5NJ is a non-latching miniature signal relay with a 5 VDC nominal coil voltage and trimmed lead terminals. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The EC2-5NJ is a non-latching miniature signal relay from the EC2 series, designed for compact and slim-package applications. It operates with a nominal coil voltage of 5 VDC, features a coil resistance of 178 Ω, and has a nominal operating power of 140 mW. This 2 Form C relay has a maximum switching current of 2 A, an operate time of approximately 2 ms, and can withstand a surge voltage of 2500 V between the coil and contacts. Due to its low power consumption and robust specifications, it is well-suited for electronic switching systems, PBX, terminal equipment, and telephone systems.

Search Keywords: EC25NJ

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Nexem
部件编号:
EC2-5NJ
计量单位:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Termination Style:
PC Pin
Coil Current:
28.09 mA
Contact Form:
2 Form C

有存货: 1,059

可立即发货

已订购: 2,030   可以发货 9/7/26

库存数量的起订量: 20

缺货数量的起订量: 20

工厂交货期 21 周

数量
Unit Price
20
$1.85
50
$1.71
100
$1.68
254
$1.61
508
$1.54
761
$1.51
1,015 +
$1.49
