NC3MAAH by neutrik
Image is representational - see mfr. specs

NC3MAAH

NEUTRIK

AA Series - 3 pole male XLR receptacle - grounding: separate ground contact to mating connector shell and front panel - horizontal PCB mount Most cost-effective round plastic body XLR PCB mount panel connector. Front panel cutout and PCB layout 100% com ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The NC3MAAH is 3 pole male XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, horizontal PCB mount The NC3MAAH has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . Most cost-effective round plastic body XLR PCB mount panel connector. Front panel cutout and PCB layout 100% compatible to A series. "Tulip" type contact design with high contact pressure for highest durability. Flammability rating UL94HB. UL recognized component.

Search Keywords: NC3MAAH

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
NEUTRIK
部件编号:
NC3MAAH
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040.00
COO:
LI
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector3389
Gender:
M3371
Body Orientation:
Right Angle3367
Mounting:
Through Hole3378
Housing Material:
Polyamide3373
Number of Contacts:
3
Contact Plating:
N/A
Termination Method:
Solder3388
Operating Temperature:
-30 to 80 °C

有存货: 907

可立即发货

工厂库存: 13,200   可以发货 5/11/26

Minimum Order Quantity: 100

Multiple: 100

工厂交货期 3 周 可以发货 5/25/26

数量
Unit Price
100
$1.052
300
$1.027
500
$0.990
1,000
$0.976
2,500
$0.973
5,000
$0.971
7,500
$0.968
10,000 +
$0.966
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
