NC3FD-V by neutrik
Image is representational - see mfr. specs

NC3FD-V

NEUTRIK

D Series - 3 pole female receptacle, vertical PCB mount - Nickel housing - silver contacts Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The NC3FD-V is 3 pole female receptacle, vertical PCB mount, Nickel housing, silver contacts The NC3FD-V has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component.

Product Highlights:

  • D-shape metal shell
  • Optimal RF protection using 3 shield contacts.
  • Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
  • Front or rear panel mount

Search Keywords: NC3FDV

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
NEUTRIK
部件编号:
NC3FD-V
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694040.00
COO:
HU
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Straight
Mounting:
Through Hole
Housing Material:
Zinc Die Cast
Number of Contacts:
3
Contact Plating:
Silver over Nickel
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

有存货: 545

可立即发货

工厂库存: 900   可以发货 5/11/26

Minimum Order Quantity: 5

工厂交货期 3 周 可以发货 5/25/26

数量
Unit Price
5
$14.24
25
$13.06
50
$12.54
100
$12.04
300
$11.24
500
$10.86
1,000
$10.36
2,500 +
$9.70
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

产品指南
