NC3FD-LX-B by neutrik
Image is representational - see mfr. specs

NC3FD-LX-B

NEUTRIK

DLX Series - 3 pole female receptacle - solder cups - black metal housing - gold contacts The DLX series features a compact all metal housing with an ingenious duplex ground contact - which offers excellent RF protection and shielding. It is the ideal m ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

3 pole female receptacle, solder cups, black metal housing, gold contacts

The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik's EMC XLR cable connector.

Product Highlights:

  • All metal housing offers best overall RF protection and electromagnetic shielding
  • New duplex ground contact for excellent contact integrity between chassis and cable connector
  • Unique cage type female contact on 3 pole version increases conductivity and reduces wear on the mated male contact
  • Female contact incorporates a solder barrier to prevent solder running into the contact mating area
  • Larger solder contacts for easier termination
  • Optional connection to easily join pin1 to chassis ground
  • D-style housing provides installation compatibility with industry standard D mounting dimensions

Search Keywords: NC3FDLXB

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
NEUTRIK
部件编号:
NC3FD-LX-B
计量单位:
Per Each
RoHS:
Yes
HTS:
8536694030.00
COO:
LI
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector3389
Gender:
F3371
Body Orientation:
Straight3367
Mounting:
Panel Mount3378
Housing Material:
N/A
Number of Contacts:
3
Contact Plating:
Gold Alloy Over Nickel3369
Termination Method:
Solder3388
Operating Temperature:
-30 to 80 °C

有存货: 287

可立即发货

工厂库存: 1,000   可以发货 5/11/26

Minimum Order Quantity: 5

工厂交货期 3 周 可以发货 5/22/26

数量
Unit Price
5
$6.49
25
$6.28
100
$6.18
300
$6.15
500
$6.11
1,000
$5.11
2,500
$5.09
5,000 +
$5.06
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
