LPF-60-24 by mean well
Image is representational - see mfr. specs

LPF-60-24

MEAN WELL

AC-DC Single output LED driver Mix mode (CV+CC); Output 24Vdc at 2.5A; cable output ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The LPF-60-24 is a 60W AC/DC LED driver featuring a dual mode constant voltage and constant current output. LPF-60-24 operates from 90 to 305VAC. Voltage output is 24 VDC and constant output current region from 14.4-24VDC with rated current of 2.5A. Thanks to the high efficiency up to 89%,with the fanless design, it is able to operate from -40℃ ~ +80℃ case temperature under free air convection. The design of metal housing and IP67 ingress protection level allows this series work for a variety of applications at dry, damp or wet loactions. The LPF-60-24 has a typical lifetime of 50000 hours and a 5-year factory warranty.

Search Keywords: LPF6024

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
MEAN WELL
部件编号:
LPF-60-24
计量单位:
Per Each
RoHS:
Yes
HTS:
8504409520
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed
Dimming:
No
Maximum Output Power:
60 W
Output Voltage Range:
14.4 to 24.0 Vdc
Maximum Output Current:
2,500 mA (2.5 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 80 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, ENEC 17, PSE, TUV
NEC Class:
2
IEC Class:
II
SELV:
Yes
LPS:
No
Warranty:
5 Years
Family:
LPF-60

有存货: 255

可立即发货

工厂交货期 16 周

数量
Unit Price
1
$27.60
5
$26.20
10
$25.10
20 +
$24.40
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
