HVG-240-54B by mean well
Image is representational - see mfr. specs

HVG-240-54B

MEAN WELL

The HVG-240-54B is a 240W AC/DC LED driver featuring a dual-mode constant voltage (54V) and constant current (4.5A) output with 3-in-1 dimming. ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

The HVG-240-54B is a 243W AC/DC LED power supply featuring a dual-mode constant voltage and constant current output. It operates over a wide input range of 180 to 528VAC and delivers a rated output of 54V at 4.5A within a constant current region of 27V to 54V. As a B-type model, it includes 3-in-1 dimming functionality (0-10VDC, 10V PWM, or resistance) and is enclosed in a metal housing with an IP67 rating for robust indoor or outdoor use. With high efficiency up to 93% and a built-in active PFC function, this fanless driver is designed for reliability in harsh environments. Common applications include LED street lighting, high-bay lighting, parking space lighting, and greenhouse lighting.

Search Keywords: HVG24054B

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
MEAN WELL
部件编号:
HVG-240-54B
计量单位:
Per Each
RoHS:
Yes
HTS:
8504409530
COO:
CN
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Current
Output Type:
Fixed, Dimmable
Dimming:
0 to 10 Vdc/PWM/Resistance
Maximum Output Power:
243 W
Output Voltage Range:
50.0 to 57.0 Vdc
Maximum Output Current:
4,500 mA (4.5 A)
Minimum AC Input Voltage:
180
Maximum AC Input Voltage:
528
Minimum DC Input Voltage:
254
Maximum DC Input Voltage:
747
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 70 °C
Safety Agency Approvals:
cRUus
IEC Class:
I
SELV:
No
LPS:
No
Warranty:
5 Years
Family:
HVG-240

有存货: 16

可立即发货

工厂交货期 16 周

数量
Unit Price
1
$93.90
5
$89.40
10
$85.50
20 +
$83.00
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
