RTE0312N04 by littelfuse/c-k
Image is representational - see mfr. specs

RTE0312N04

Littelfuse/C&K

Switch DIP N.O./N.C. SP3T 3 Shaft 0.1A 30VDC PC Pins 1500Cycles 2.54mm Thru-Hole Tube ...

产品说明书
符合 RoHS 规定
包装
附件
Request Programming Quote
Discontinued & Replaced
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

描述

RTE0312N04 is a low profile rotary DIP switch from the RTE Series, featuring a 3-position SP3T configuration with ESD protection and an extended shaft actuator. This thru-hole mounted switch offers gold-plated contacts with matte-tin terminal plating, providing a contact rating of 100 mA max at 30 V DC max. The switch features a robust stainless steel cover with thermoplastic PPS base, contact resistance of 100 mO max initial, insulation resistance of 10^13 O min, and dielectric strength of 500 Vrms. Operating temperature ranges from -25°C to 85°C with a mechanical life of 1,500 actuations. Ideal for timers, automation components, computer peripherals, alarms, access control, and instrumentation applications.

Search Keywords: RTE0312N04

规格

Product Attribute
Attribute Value
Select Attribute
Products found: 0
供应商:
Littelfuse/C&K
部件编号:
RTE0312N04
Alias/AKA:
Y36B12003FPLFT
计量单位:
Per Each
RoHS:
Yes
HTS:
8536509020
COO:
FR
ECCN:
EAR99
供应商标准包装: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Body Orientation:
Straight
Actuator Style:
Shaft
Actuator Length:
3.9 mm
Number of Positions:
3
Pole Throw Configuration:
SP3T
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@30VDC A
Contact Plating:
Gold
Terminal Pitch:
2.54 mm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

有存货: 3,291

Ships today, if you order in

Minimum Order Quantity: 100

PRICE (USD)

数量
Unit Price
100
$1.93
250
$1.82
500
$1.73
1,000
$1.59
2,500
$1.55
5,000
$1.48
7,500 +
$1.46
