描述
The D502J12S215DQA is a miniature snap-in power rocker switch from the D Series, designed for general-purpose switching applications requiring reliable performance and compact form factor. This switch features a 10 A rating at 125 VAC (50/60 Hz) for general-purpose use and 10 A at 30 VDC for resistive loads, with silver contact material (QA option) and extended PC thru-hole termination (06 option). The switch incorporates a rocker actuator with white housing (option code 1) and black actuator (option code 2), providing clear visual feedback for switch position. With an electrical life of 10,000 make-and-break cycles at full load, insulation resistance of 10? O minimum, and dielectric strength of 1,000 Vrms, this switch is well-suited for small appliances, computers and peripherals, and medical instrumentation where reliable switching and compact mounting are essential.
搜索关键词: D502J12S215DQA
规格
常见问题
D502J12S215DQA 是否符合 RoHS 标准？
是的，D502J12S215DQA 符合 RoHS 标准。
D502J12S215DQA 的交货期是多少？
D502J12S215DQA 的标准交货期约为 8 周。有库存的数量由 Master Electronics 发货。
有存货: 563
发货 today, 输入设置值。
最小订购数量: 36
此消息模板用于通知联盟会员某个订单已付款。当金额被扣款时，订单会获得已付款状态。: 36
工厂交货期 8 周
价格 (USD)
工具/3D模型
Product Drawing
数据表
