描述
1201M2S3AQE2 is a miniature DPDT slide switch from the C&K 1000 Series, designed for power switching applications. It features silver contact material with a contact rating of 6 AMPS @ 120 V AC or 28 V DC, and 3 AMPS @ 250 V AC, along with quick connect termination and epoxy terminal seal for bottom-wash cleaning compatibility. The switch offers contact resistance below 10 mO typical, insulation resistance of 10? O minimum, and dielectric strength of 1,000 Vrms minimum at sea level. With an operating temperature range of -30°C to 65°C and electrical life of 40,000 make-and-break cycles at full load, this RoHS compliant switch is suitable for test and measurement equipment, telecommunications, and computer peripherals.
搜索关键词: 1201M2S3AQE2
规格
常见问题
1201M2S3AQE2 是否符合 RoHS 标准？
是的，1201M2S3AQE2 符合 RoHS 标准。
1201M2S3AQE2 的交货期是多少？
1201M2S3AQE2 的标准交货期约为 8 周。有库存的数量由 Master Electronics 发货。
有存货: 354
可立即发货
最小订购数量: 5
工厂交货期 8 周
工具/3D模型
Product Drawing
数据表
